32MM　LEVER,TAPE GUIDE F.

SMT industry a large number of wholesale...

The company has developed and yamaha YS electronic feeder accessories.

The company a large number of wholesale YAMAHA SS electric feida accessories.

Japan original factory imported technology, the quality guaranteed, the same as the original life, the lowest price.

Welcome to inquire! Welcome the SMT counterparts to wholesale!

No. Part No. Part Name Q'ty Remarks
1 KHJ-MC103-02 BLOCK,FRONT 1
2 KHJ-MC104-00 RAIL,UNDER 1
3 KHJ-MC105-00 PIN,TAIL 1
4 KHJ-MC10F-00 SCREW,FLAT HEAD 2
5 KHJ-MC53N-00 PIN,DOWEL 1
6 90990-09J008 SCREW,FLAT HEAD 2
7 KHJ-MC281-00 HANDLE 1
8 KHJ-MC182-00 TENSION,WIRE 1 1
9 KHJ-MC183-00 SPACER,TENSION 1 1
10 KHJ-MC184-00 SPACER,TENSION 2 1
11 KHJ-MC286-00 WIRE,UNCLAMP 1
12 KHJ-MC187-00 SPRING,TENSION 1
13 KHJ-MC289-00 PIN,CLAMP 1
14 KHJ-MC18A-00 SPRING,CLAMP 1
15 KHJ-MC28B-00 COVER,WIRE 1 1
16 KHJ-MC58G-00 SHAFT,HANDLE SUPPORT 1
17 KHJ-MC28H-00 CLAMP LEVER ASSY. 1
18 90990-14J001 CIRCLIP (E) 1
19 90189-05J056 NUT,HEXAGON 1
20 90440-01J030 CIRCLIP(E) 1
21 91317-03008 BOLT HEX.SOCKET HEAD 4
22 91317-05016 BOLT HEX.SOCKET HEAD 1
23 92A08-03303 SET SCREW M3X3 1
24 92A08-03305 SCREW,SET 1
25 99480-03010 PIN,PARALLEL 2
26 99480-04018 PIN,PARALLEL 1
27 99480-05014 PIN,PARALLEL 1
28 KHJ-MC10S-00 PIN,LOCATE 1 1
29 KHJ-MC10T-00 PIN,LOCATE 2
