YAMAHA SS12/16mm Feeder Parts List
Part No. Part Name
KHJ-MC201-00 BODY,FEEDER
KHJ-MC202-00 COVER,FEEDER SIDE
KHJ-MC20C-00 SEAL,MAIN LABEL
KHJ-MC10E-00 SCREW,FLAT HEXLOBE
KHJ-MC210-00 MOTOR, FEED
KHJ-MC134-00 GEAR,IDLE F1
KHJ-MC135-00 GEAR,IDLE F2
KHJ-MC136-01 GEAR,IDLE F3
KHJ-MC137-00 GEAR,IDLE F4
KHJ-MC238-00 GEAR,DRIVEN
KHJ-MC239-00 SHAFT,IDLE GEAR
KHJ-MC23B-00 BUSH,SPROCKET
KHJ-MC23C-00 PLATE,PUSHER GEAR
KHJ-MC13D-00 SPRING,PUSHER PLATE
KHJ-MC13F-00 SCREW,STAD
KHJ-MC13P-00 SPACER,F3
KHJ-MC23G-000 SHAFT,GEAR DRIVEN
KHJ-MC206-00 PLATE,UNDER
KHJ-MC261-00 BOX,TOP TAPE
KHJ-MC262-00 COVER,TOP TAPE BOX
KHJ-MC165-00 MAGNET,TAIL
KHJ-MC266-00 BLOCK,P/O TOOTH
KHJ-MC16J-00 SCREW,FLAT HEAD
KHJ-MC26L-00 PLATE,GUIDE
KHJ-MC26M-00 PLATE,GUIDE
KHJ-MC26N-00 PLUNGER
KHJ-MC46T-00 BOLT HEX.S/H LOW
KHJ-MC26U-00 TAIL COVER ASSY.
90166-02JA03 SCREW,PAN HEAD
98707-03006 SCREW,FLAT HEAD
99480-03010 PIN,PARALLEL
KHJ-MC20C-00 SEAL,MAIN LABEL
KHJ-MC132-00 SPROCKET
KHJ-MC23A-00 SHIM,SPROCKET
KHJ-MC23E-00 BOLT HEX.S/H LOW
KHJ-MC241-00 TAPE GUIDE ASSY.
KHJ-MC241-01 TAPE GUIDE ASSY
KHJ-MC241-02 TAPE GUIDE ASSY
KHJ-MC241-03 TAPE GUIDE ASSY
KHJ-MC244-00 LEVER,TAPE GUIDE R
KHJ-MC245-00 LEVER,TAPE GUIDE F
KHJ-MC245-01 LEVER,TAPE GUIDE F
KHJ-MC146-02 SPRING,TAPE GUIDE R
KHJ-MC247-00 SPRING,TAPE GUIDE F
KHJ-MC247-01 SPRING,TAPE GUIDE F
KHJ-MC167-00 COVER,MENBRANE
KHJ-MC16J-00 SCREW,FLAT HEAD
KHJ-MC26K-00 COVER,MENBRANE
KHJ-MC1A5-00 DUMMY SPLICE SENS.
KHJ-MC1AA-00 SWITCH,OPERATION
KHJ-MC24D-00 PLATE,GUIDE
KHJ-MC1AB-00 SCREW,PAN HEAD TAP.
98707-03006 SCREW,FLAT HEAD
92A08-03303 SET SCREW M3X3
99480-04022 PIN,PARALLEL
KHJ-MC24J-00 TAPE GUIDE ASSY
KHJ-MC24J-01 TAPE GUIDE ASSY
KHJ-MC24J-02 TAPE GUIDE ASSY.
KHJ-MC10E-00 CREW,FLAT HEXLOBE
KHJ-MC210-10 MOTOR, PEEL
KHJ-MC13F-00 SCREW,STAD
KHJ-MC251-00 GEAR,IDLE P1
KHJ-MC252-00 GEAR,IDLE P2
KHJ-MC253-00 GEAR,IDLE P3
KHJ-MC254-00 GEAR,IDLE P4
KHJ-MC256-00 ROLLER,PEEL OFF
KHJ-MC258-00 COVER,IDLE GEAR
KHJ-MC259-00 COVER,IDLE GEAR
KHJ-MC25A-00 SUB-ROLLER,
KHJ-MC25B-00 SHAFT,IDLE GEAR P3
KHJ-MC25C-00 SHAFT,IDLE GEAR P4
KHJ-MC25D-00 SHAFT,ROLLER
KHJ-MC25E-00 COVER,IDLE GEAR
KHJ-MC26E-00 SPRING,P/O LEVER
KHJ-MC16H-00 SCREW,PAN HEAD TAP.
KHJ-MC26V-00 P/O LEVER ASSY.
KHJ-MC1A1-00 BOX,EL
KHJ-MC1A2-00 COVER,BOX EL
KHJ-MC1A6-00 SCREW,FLAT HEXLOBE T
KHJ-MC1A9-00 CONNECTOR,BOARD
KHJ-M4488-00 FEEDER BOARD ASSY
90115-2AJ008 BOLT HEX.SOCKET HEAD
90166-02JA03 SCREW,PAN HEAD
90166-02JA08 SCREW PAN H.:M2.5X8
91317-03006 BOLT HEX.SOCKET HEAD
92A08-03303 SET SCREW M3X3
99480-05018 PIN,PARALLEL
KHJ-MC103-02 BLOCK,FRONT
KHJ-MC104-00 RAIL,UNDER
KHJ-MC105-00 PIN,TAIL
KHJ-MC10F-00 SCREW,FLAT HEAD
KHJ-MC16J-00 SCREW,FLAT HEAD
KHJ-MC281-00 HANDLE
KHJ-MC182-00 TENSION,WIRE
KHJ-MC183-00 SPACER,TENSION
KHJ-MC184-00 SPACER,TENSION
KHJ-MC286-00 WIRE,UNCLAMP
KHJ-MC187-00 SPRING,TENSION
KHJ-MC289-00 PIN,CLAMP
KHJ-MC18A-00 SPRING,CLAMP
KHJ-MC28B-00 COVER,WIRE
KHJ-MC18F-00 CIRCLIP (E)
KHJ-MC28H-00 CLAMP LEVER ASSY.
90440-01J030 CIRCLIP(E)
91317-03008 BOLT HEX.SOCKET HEAD
92A08-03303 SET SCREW M3X3
99480-03010 PIN,PARALLEL
99480-04018 PIN,PARALLEL
99480-05012 PIN,PARALLEL
KHJ-MC10S-00 PIN,LOCATE
KHJ-MC10T-00 PIN,LOCATE
KHJ-MC201-00 BODY,FEEDER
KHJ-MC202-00 COVER,FEEDER SIDE
KHJ-MC20C-00 SEAL,MAIN LABEL
KHJ-MC10E-00 SCREW,FLAT HEXLOBE
KHJ-MC210-00 MOTOR, FEED
KHJ-MC134-00 GEAR,IDLE F1
KHJ-MC135-00 GEAR,IDLE F2
KHJ-MC136-01 GEAR,IDLE F3
KHJ-MC137-00 GEAR,IDLE F4
KHJ-MC238-00 GEAR,DRIVEN
KHJ-MC239-00 SHAFT,IDLE GEAR
KHJ-MC23B-00 BUSH,SPROCKET
KHJ-MC23C-00 PLATE,PUSHER GEAR
KHJ-MC13D-00 SPRING,PUSHER PLATE
KHJ-MC13F-00 SCREW,STAD
KHJ-MC13P-00 SPACER,F3
KHJ-MC23G-000 SHAFT,GEAR DRIVEN
KHJ-MC206-00 PLATE,UNDER
KHJ-MC261-00 BOX,TOP TAPE
KHJ-MC262-00 COVER,TOP TAPE BOX
KHJ-MC165-00 MAGNET,TAIL
KHJ-MC266-00 BLOCK,P/O TOOTH
KHJ-MC16J-00 SCREW,FLAT HEAD
KHJ-MC26L-00 PLATE,GUIDE
KHJ-MC26M-00 PLATE,GUIDE
KHJ-MC26N-00 PLUNGER
KHJ-MC46T-00 BOLT HEX.S/H LOW
KHJ-MC26U-00 TAIL COVER ASSY.
90166-02JA03 SCREW,PAN HEAD
98707-03006 SCREW,FLAT HEAD
99480-03010 PIN,PARALLEL
KHJ-MC20C-00 SEAL,MAIN LABEL
KHJ-MC132-00 SPROCKET
KHJ-MC23A-00 SHIM,SPROCKET
KHJ-MC23E-00 BOLT HEX.S/H LOW
KHJ-MC241-00 TAPE GUIDE ASSY.
KHJ-MC244-00 LEVER,TAPE GUIDE R
KHJ-MC245-00 LEVER,TAPE GUIDE F
KHJ-MC146-00 SPRING,TAPE GUIDE R
KHJ-MC247-00 PRING,TAPE GUIDE F
KHJ-MC167-00 COVER,MENBRANE
KHJ-MC16J-00 SCREW,FLAT HEAD
KHJ-MC26K-00 COVER,MENBRANE
KHJ-MC1A5-00 DUMMY SPLICE SENS.
KHJ-MC1AA-00 SWITCH,OPERATION
KHJ-MC24D-00 PLATE,GUIDE
KHJ-MC1AB-00 SCREW,PAN HEAD TAP.
98707-03006 SCREW,FLAT HEAD
92A08-03303 SET SCREW M3X3
99480-04022 PIN,PARALLEL
KHJ-MC10E-00 SCREW,FLAT HEXLOBE
KHJ-MC210-10 MOTOR, PEEL
KHJ-MC13F-00 SCREW,STAD
KHJ-MC251-00 GEAR,IDLE P1
KHJ-MC252-00 GEAR,IDLE P2
KHJ-MC253-00 GEAR,IDLE P3
KHJ-MC254-00 GEAR,IDLE P4
KHJ-MC256-00 ROLLER,PEEL OFF
KHJ-MC258-00 COVER,IDLE GEAR
KHJ-MC259-00 COVER,IDLE GEAR
KHJ-MC25A-00 SUB-ROLLER,
KHJ-MC25B-00 SHAFT,IDLE GEAR P3
KHJ-MC25C-00 SHAFT,IDLE GEAR P4
KHJ-MC25D-00 SHAFT,ROLLER
KHJ-MC25E-00 COVER,IDLE GEAR
KHJ-MC26E-00 SPRING,P/O LEVER
KHJ-MC16H-00 SCREW,PAN HEAD TAP.
KHJ-MC26V-00 P/O LEVER ASSY.
KHJ-MC1A1-00 BOX,EL
KHJ-MC1A2-00 COVER,BOX EL
KHJ-MC1A6-00 SCREW,FLAT HEXLOBE T
KHJ-MC1A9-00 CONNECTOR,BOARD
KHJ-M4488-00 FEEDER BOARD ASSY
90115-2AJ008 BOLT HEX.SOCKET HEAD
90166-02JA03 SCREW,PAN HEAD
90166-02JA08 SCREW PAN H.:M2.5X8
91317-03006 BOLT HEX.SOCKET HEAD
92A08-03303 SET SCREW M3X3
99480-05018 PIN,PARALLEL
KHJ-MC103-01 BLOCK,FRONT
KHJ-MC104-00 RAIL,UNDER
KHJ-MC105-00 PIN,TAIL
KHJ-MC10F-00 SCREW,FLAT HEAD
KHJ-MC16J-00 SCREW,FLAT HEAD
KHJ-MC281-00 HANDLE
KHJ-MC182-00 TENSION,WIRE
KHJ-MC183-00 SPACER,TENSION
KHJ-MC184-00 SPACER,TENSION
KHJ-MC286-00 WIRE,UNCLAMP
KHJ-MC187-00 SPRING,TENSION
KHJ-MC289-00 PIN,CLAMP
KHJ-MC18A-00 SPRING,CLAMP
KHJ-MC28B-00 COVER,WIRE
KHJ-MC18F-00 CIRCLIP (E)
KHJ-MC28H-00 CLAMP LEVER ASSY.
90440-01J030 CIRCLIP(E)
91317-03008 BOLT HEX.SOCKET HEAD
92A08-03303 SET SCREW M3X3
99480-03010 PIN,PARALLEL
99480-04018 PIN,PARALLEL
99480-05012 PIN,PARALLEL
